ATX300

4G ATEX Rugged Smartphone

The ATX300 is a rugged 4G ATEX smartphone designed for professional communications in industrial environments with specific safety requirements. It combines a 4-inch touchscreen, advanced connectivity, Push-to-Talk functionality, and dedicated physical controls with a reinforced IP68 construction, compliant with MIL-STD-810H and ATEX/IECEx certified, making it suitable for demanding conditions and potentially explosive atmospheres.

4g LTE

IP68

Drop resistance

Push To Talk (PTT)

4000 mAh battery

MIL-STD-810H

ATEX Zone 1/21

General

Device type: 4G ATEX Rugged Smartphone
GSM frequencies: 850 / 900 / 1800 / 1900 MHz
WCDMA bands: B1 / B5 / B8
LTE bands: B1 / B3 / B5 / B7 / B8 / B18 / B19 / B20 / B26 / B28a&b / B34 / B38 / B39 / B40 / B41
SIM: Dual Nano SIM (4FF)
Languages: English by default. Multilingual interface supporting the native languages available in
Android 14
Antenna: Integrated into the device
Use: Portable / handheld
Operating environment: Designed for industrial environments and potentially explosive atmospheres
Material: PC + TPU
Color: Black + Blue

Dimensions and Weight

Dimensions: 147.5 × 70.5 × 24.8 mm
Weight: 325 g
Design: Ergonomic design for one-handed operation

Sturdiness

Protection rating: IP68
Drop resistance: Up to 1.5 m
Ruggedness standard: Compliant with MIL-STD-810H
ATEX protection: Zone 1/2
Gas marking: II 2 G Ex ib IIC T4 Gb
Dust marking: II 2 D Ex ib IIIC T130 °C Db
Operating temperature: -20 °C ~ +55 °C
Operating humidity: 10% ~ 90%
Operating environment: Designed for industrial environments with ATEX requirements
Protected battery: Screw-lock mechanism
Glove operation: Supported
Wet-hand operation: Supported

PTT and professional controls

Push-to-Talk: Dedicated physical PTT button
PoC: Supports Push-to-Talk over Cellular
Professional platforms: Compatible with professional communication platforms
Emergency: Dedicated SOS button
Function keys: Dedicated FN button
Interface management: Recent apps, home, and back buttons
Volume control: Physical volume + / – buttons
Power: Physical power button

Display

Size: 4”
Technology: TFT
Type: Touchscreen
Resolution: 540 × 1080 px

Processor

Chipset: MediaTek MT6765

Operating System

Operating system: Android 14

Memory

RAM: 6 GB LPDDR4x
Internal storage: 128 GB
External storage: MicroSD Class 4 up to 256 GB

Connectivity

Bluetooth: Bluetooth 5.1
Wi-Fi: IEEE 802.11ac/a/b/g/n
Wi-Fi Hotspot: Yes
NFC: Yes
USB: USB Type-C for charging and data transfer
SIM: 2 × Nano SIM (4FF)
MicroSD: 1 × MicroSD card slot
Magnetic charging: Supported
Charging dock: Supported

Network and data

LTE: Cat 4
LTE speed: Up to 150 Mbps download / 50 Mbps upload
VoLTE: Yes, HD voice
VoWiFi: Yes
SMS over Wi-Fi: Supported via VoWiFi

Positioning

GPS: Yes
BeiDou: Yes
GLONASS: Optional
A-GPS: Optional
Galileo: Yes

Supported Services

Call features: RRedial, call waiting, call transfer, and multi-party conference calls
Call services: Fixed dialing, call forwarding, call waiting, and call barring
VoLTE: HD Voice over LTE networks
VoWiFi: Voice and SMS over Wi-Fi networks
SMS: Yes
Push-to-Talk over Cellular (PoC): Yes
FOTA: Remote software management and updates
